| flexible
series 1T |
rigid
series 2T |
| circuit ground: |
circuit ground: |
| 125µm polyester |
backelite,epoxy-glass |
| thermostabilized |
polycarbonate, glass |
| |
any thickness |
| |
|
| connections: |
connections: |
| crimped connectors |
rivets, screws |
| ZIF connectors |
spring (front side) |
| |
|
| |
|
| |
|
| type: |
type: |
| 1T flat overlay |
2T flat overlay |
| 1TF embossed keys |
2TF embossed keys |
1TC metal domes
under flat overlay |
2TC metal domes
under flat overlay |
1TCF embossed keys
and metal domes |
2TCF embossed keys
and metal domes |
1TB transparent keys
(for back-lit keyboards) |
2TB trasparent keys
(for back-lit keyboard) |
1TBF transparent keys
embossed |
2TBF trasparent keys
embossed |
| |
2TG silicon rubber keypads |
|
| flexible
series 3T |
rigid
series 4T |
| circuit ground: |
circuit ground: |
| 200µm polyester |
FR2 o FR4 1,6 mm |
| |
|
| |
|
| |
|
| connections: |
connections: |
| solderable pads |
solderable pads |
| crimped connectors |
male strip |
| ZIF connectors |
terminal board |
| |
rivets, screws |
| |
|
| type: |
type: |
| 3T flat overlay |
4T flat overlay |
| 3TF embossed keys |
4TF embosed keys |
3TC metal domes
under flat overlay |
4TC metal domes
under flat overlay |
3TCF embossed keys
and metal domes |
4TCF embossed keys
and metal domes |
|
|
|
|
| |
4TG silicon rubber keypads |
|
